Testing Equipments
The CRASH-UdeS facilities includes a collection of equipments allowing to perform a large number of experiments.
To help you in the handling of this type of equipment, a series of videos (in French), produced by the CRASH-UdeS, propose some reminders about the use of certain laboratory equipment.
- Dimensions: 36" x 36" x 23", approximately 0.5m3. Data sheet.
- Basin equipped with aluminum frames and a mounting plate, allowing the integration of various devices, even a collaborative robotic arm.
- Square array of 96 loudspeakers designed by Sonic Emotion, for WFS reproduction.
- Spherical array of 50 loudspeakers, designed at CRASH-UdeS, for ambisonics reproduction.
- Modular array, up to 196 1/4" B&K Type 4957 microphones.
- Acquisition and conditionning for 196 channels, allowing the interfacing with the BK Connect software.
Large set of sensors/actuators, for mechanical tests:
- Accelerometers
- Acoustic sources
- Contact and immersion transducers (0.5 to 20 MHz)
- Force sensors
- Hot wire anemometer
- Mechanical exciters
- Microphones
- Scanivalves
- Ultrasonic detection probe
- Ultrasound probe
and others.
- Micropress
- Micropunching machine
- Thermoforming machine
- Twin screw extruder
- Verasonics Vantage 128 model.
- 2D and 3D ATL probes.
- Ultrasonic phantom, multipurpose and multi-fabric, 040GSE from CIRS.
Polytec PSV-500-3D model, on a robotic stand.
